ZUGMASCHINE MODELS ONLY
REAR HITCH (ZUGMASCHINE ONLY)
NOTICE
After 1000 km of use, tighten the bolt holding the trailer ball to the hitch to 445
N⋅m.
Use the rear hitch (if equipped) for towing a trailer. See the Hauling Cargo
section for details and procedures.
The values given below pertain to factory-installed hitches and are provided for
informational purposes only.
IMPORTANT
For vehicle-specific trailering values, see the Specifications chapter.The
vehicle-specific values take precedent if they are lower than the component
values shown below.
REAR HITCH COMPONENT SPECIFICATIONS
Maximum Vertical Load (S) (85 kg)
Maximum Towable Mass (2000 kg)
Maximum Dynamic Force (D) 10,2 kN
Approval # E20 55R-01 4430
REAR HITCH CERTIFICATION LABEL
(ZUGMASCHINE ONLY)
The hitch certification label is located
near the hitch on models equipped with
a factory-installed rear hitch.
53
FEATURES AND CONTROLS
