Engage the AWD before getting into conditions where front wheel drive may be
needed. If the rear wheels are spinning, release the throttle before switching to
AWD.
NOTICE
Switching to AWD while the rear wheels are spinning may cause severe drive
shaft and clutch damage. Always switch to AWD while the rear wheels have
traction or are at rest.
DISENGAGING AWD
Move the AWD switch to the center or bottom position to disengage AWD. If the
switch is turned off while the front hubs are driving, they will not release until the
rear wheels regain traction.
In some situations, the front gearcase may remain locked after turning the AWD
switch off. If this occurs, you may notice increased steering effort and some
vehicle speed restriction. Perform the following procedure to unlock the front
gearcase.
To disengage AWD, do the following:
1. Stop the vehicle.
2. Operate in reverse for at least 10 feet (3 m).
3. Stop completely.
4. Shift into low gear and drive forward.
5. If the front gearcase remains locked after following these instructions, see
your dealer or other qualified service person for service.
LOCKING THE DIFFERENTIAL
Move the rocker switch to the center position to lock the differential and operate
in two wheel drive (2WD). Locking the differential in slippery or low traction
conditions helps improve traction. When the rear differential is locked, both rear
wheels rotate at the same speed.
UNLOCKING THE DIFFERENTIAL (TURF MODE)
When operating in TURF mode, the inside rear wheel will rotate independently
from the outside wheel during turns. Operate in TURF mode only as needed to
protect smooth, level surfaces from tire damage. DO NOT operate in TURF
mode when climbing or descending hills, when sidehilling, or when operating on
uneven, loose, or slippery terrain such as sand, gravel, ice, snow, obstacles, and
water crossings. Always operate in AWD on these types of terrain.
80
OPERATION
