51
FEATURES
Instrument Cluster
Your ATV is equipped with an instrument cluster that senses vehicle
speed from the right front wheel. The instrument cluster measures
distance in miles as well as hours of operation. It also includes a
reverse speed limiter function that limits the ATV’s speed to
approximately 7-9 mph. Refer to page 37 for additional information.
1. Rider Information C enter
2. Speedometer needle - in addition to depicting vehicle speed, this
needle will flash to signal a fault condition.
3. Speedometer
2
3
1
CAUTION
Washing the ATV with a high pressure washer may cause water to
enter the instrument cluster and cause damage to the electronic
components. Wash the ATV by hand or with a garden hose using
mild soap. Do not use alcohol to clean the instrument cluster.
Immediately clean off any gasoline that splashes on the instrument
cluster.
