Polaris msx 110

ABCDE F G H
1
3
2
4
ABCDE F G H
1
3
2
4
ABC D E F GH JK L M
1
3
2
4
ECU 300 (Black)
ECU 100 (Grey)
Crankshaft
Sensor
1
2
3
1
2
3
B1 Crank Signal A
B2 Crank Signal B
A3 Ground Reference
FUEL INJECTION / IGNITION / EXHAUST SYSTEMS
5.232004 Four Stroke PWC Service Manual
Engine Crankshaft Positio n (Engin e Speed) Sensor Circuit
Circuit Trouble Codes
P -- Code Description Summary
P0335 Loss of Synchronization The number of pulses, or teeth on the timing rotor are not cor-
rect.
P0336 Engine Speed Sensor: Signal Error The engine speed sensor signal is not valid.
P0337 Engine Speed Sensor: Low Limit The engine speed signal voltage is outside the acceptable range.
P0338 Engine Speed Sensor: High Limit The engine speed signal voltage is outside the acceptable range.
