PROPULSION
6.132004 Four Stroke PWC Service Manual
Stator Disassembly -- Continued
4. Remove stator assembly from vise. Using a
soft--faced hammer, tap stub shaft out of housing.
5. Inspect shaft and collar for wear, scratches, or
damage. Install new o--rings upon reassembly.
6. Using a brass hammer or aluminum drift, tap bearing
spacer to one side of the stator housing. Drive out
bearings by taping on inner races.
7. Measure spacer with a Vernier caliper. Replace if worn
beyond service limit. If the spacer is too short, the
bearings will be side--loaded and premature wear will
result.
Bearing Spacer Length
Service Limit: 1.730″ (43.94 mm)
