Polaris msx 110

--
+
STARTER RELAY
C
F
B
D
E
A
2A
10A
15A
START SWITCH
TETHER SWITCH
A
B
START SWITCH / STOP -- TETHER
B
C
A
ECU
ECU 100
ECU 200
ECU 300
B4
D
D
ENGINE HARNESS--TO--CHASSIS
HARNESS CONNECTOR
PURPLE
PURPLE
YEL/RED
RED
RED
YEL/RED
BLK
RED
RED/PUR
START / STOP CIRCUITS -- LEGEND
RED 12V BATTERY VOLTAGE
BLACK GROUND
RED/PUR FUSE P ROTECTED / SWITCHED BATTERY VOLTAGE
YEL/RED STARTER RELAY SIGNAL
RED/YEL STARTER RELAY SIGNAL
PURPLE SWITCHED ECU VOLTAGE
BLU/WHT SWITCHED ECU VOLTAGE
Rev. B 1/19/2004
L4
BLK
H C
BLU/WHT
SYSTEM INTERF ACE BOX
F
F
A
RED/YEL
YEL/RED
PURPLE
ELECTRICAL SYSTEMS
8.10
2004 Four Stroke PWC Service Manual
Start / Stop Electrical System
