ENGINE DISASSEMBLY / ASSEMBLY
4.6
2004 Four Stroke PWC Service Manual
Oil Storage Tank / Oil Coo ler Specific F asten er Torque Specifications
Component FT. LBS. Nm Notes Fastener(s)
Oil Separator Fastener Hand Tighten K80 x30
Separator Oil Return Fitting 7 10 Banjo Bolt
Oil Cooler -- to -- Intercooler Bracket 7 10 M6 x 20
Oil Storage Tank Rollover Valve 7 10 Banjo Bolt
Oil Storage Tank Pullover Gear Clamp 2 3
High Pressure Oil Hose Connections
(Turbocharger / Rollover V alve)
7 10 M10 x 1
Banjo Bolt
Gear Clamp Torque Specifications
8 -- 16mm = 2 Nm
Over 16mm = 2.4 Nm
NOTE: Some or all clamps may be Oetikert clamps.
