Page 17
ENGLISH
Polaris
®
PB4-60 Booster Pump
|
Installation and Operation Manual
NOTE When installing pump, leave a minimum of 2.0 feet (60 cm) of clearance above the pump for
service.
7.3 Pump Dimensions
Bolt Holes,
Center to Center
Front Edge of Union
to Center of Bolt Holes
4 "
15
/
16
6
3
/
8
"
8
13
/
16
"
15
1
/
16
"
1
9
/
16
"
11
1
/
2
"
13
/
16
"
5
22.4 cm
38.3 cm
4 cm
29.2 cm
14.8 cm
12.5 cm
16.2 cm
Figure 12. Polaris PB4-60 Booster Pump Dimensions
