62
SPECIFICATIONS
General Specifications
ALTERNATOR
Model P1000i P2000i
Rated Frequency (Hz) 50
Rated Voltage (V) 240
Rated Current (A) 3.75 6.67
Max Current (A) 4.17 8.33
DC Output Voltage 12V (5A)
Rated Output 900 W 1600 W
Maximum Output 1000 W 2000 W
Phase Single
ENGINE
Model KG144 KG158
Type Single cylinder, 4 stroke, vertical shaft, air-cooled, OHV
Displacement (cc) 58 106
Engine Oil
POLARIS 5W-30 Generator Oil
Engine Oil Capacity qt (L) (0.25 or 0.26 L .42(.4)
Intake Valve Clearance 0.18-0.10 mm (0.0031-0.0039 in.)
Exhaust Valve Clearance 0.10-0.15 mm (0.0039-0.0059 in.)
Spark Plug-Gap UR5 - 0.6 - 0.7 mm (0.024 - 0.028 in.)
GENERAL
Fuel 91 Octane (Up to 10% Oxygenated)
Fuel Tank Capacity 2.6 L (0.7 gallons) 3.8 L (1 gallon)
Starting System Recoil
Dimensions (L x W x H)
493 mm x 264 mm x 419 mm
(19.4 in. x 10.4 in. x 16.5 in.)
545 mm × 330 mm × 448mm
(21.4in. x 13 in. x 17.6 in.)
Weight
16.5 kg (36.4 lbs.) 24.18 kg (53.3 lbs.)
Full Tank Run Time
Hours at Rated Load
4 Hours 3.5 Hours
AC Circuit Breaker Electronic
DC Fuse 5 Amp
DC Charging Cord Standard
