Polaris Power P2000i User Manual

65
WIRING DIAGRAMS
P2000i Wiring Diagram
Inverter Module
Blue
Red
Brown
Pink(Black)
Orange(Red)
White
White
Black Black
Black Yellow
Blue
Secondary winding
Primary winding
Stepping motor
DC receptacle
Charging winding
Blue
Red
Black
Rectifier
Black
White
Gray
Reset switch
Smart Throttle Switch
Black
Red
Stop switch
Ignition winding
Trigger winding
Low oil pressure switch
Spark plug
Ignition coil
Red
Red
Red
Working indicator
Overload indicator
Low oil indicator
Black White
Brown
Gray
Red
Green
Purple
Orange
Blue
Yellow green
Parallel output
Single-phase
receptacle
Red
Green
Yellow green
Purple
Orange
Blue
Yellow green
Yellow green
