116
MAINTENANCE AND LUBRICATION
Lights
Headlight Assembly Replacement
1. Remove the wire harness connector from the
headlights.
2. Remove the front cab (see page 120).
Position the cab upside down on a soft
protective surface to prevent scratching.
3. Remove the small adjuster bracket (1) and
install it on the new lamp.
4. Remove the large pivot bracket (2) and remove
the headlamp.
1
2
