150
ADJUSTMENTS
Rear Suspension
Rebound Damping
1. Locate the rebound damping clicker drum between
the lower spring seat and the lower shock mount.
2. Use a screwdriver make the adjustment. Turn t he
clicker counter-clockwise to decrease the rebound
damping (A). Turn the clicker clockwise to increase
rebound damping (B).
NOTE: The rebound damping is factory set at 16
clicks from fully closed. See Suspension
Settings on page 146.
A
B
