120
MAINTENANCE AND LUBRICATION
Front Cab Removal
1. Remove the screws and washers (1) from
the front left-hand and right-hand cab
mounts.
2. Remove the wire harness connector from the
headlights.
3. Loosen the screw (2) located inside the cab
under the front cover.
4. Gently pull the cab forward to remove the
cab and disengage it from the stand-offs on
the fuel tank.
5. Reverse all steps to reinstall the front cab.
2
1
