DISPLAY AREA FUNCTION
r
Fuel Gauge
The segments of the fuel gauge show the level of fuel in
the fuel tank. When the last segment clears, a low fuel
warning is activated. All segments including the fuel icon
will flash. Refuel immediately.
t
Service
Indicator
A flashing wrench symbol alerts the operator that the
preset service interval has been reached. Your POLARIS
dealer can provide scheduled maintenance. See page
55 for more information.
y
Clock (if
equipped)
The clock displays time in a 12-hour or 24-hour format.
u
AWD Indicator
Segments of the indicator illuminate based on drive
mode engaged.
INDICATOR LAMPS
Indicator Icon Function
Check Engine
This lamp illuminates when the ECM detects a
Diagnostic Trouble Code in the engine
management system. Do not operate the
vehicle if this warning appears. Serious engine
damage could result. Your authorized POLARIS
dealer can assist. This lamp will also illuminate
if the vehicle is keyed on but not started; it will
turn off once the vehicle is started.
EPS Warning (if
equipped)
This lamp illuminates to indicate that EPS has
shut down. EPS shuts down automatically 5
minutes after the engine is turned off if the key
remains in the ON position. Turn the key off and
on to reset the unit. If the light remains on after
starting the engine, the EPS system is
inoperative. Your POLARIS dealer can assist.
Engine Hot
This lamp illuminates to indicate an overheated
engine. If the indicator flashes, a severe
overheating condition exists and the engine will
shut down automatically. The vehicle will not
start again until the engine has sufficiently
cooled down. Whenever this lamp illuminates,
the engine load should be reduced in any way
possible to avoid overheating and shutting down
the engine.
43
FEATURES AND CONTROLS
