6. If hub nut was removed, install a new cotter pin after the hub nut has been
tightened. If the holes do not line up, turn the hub nut until the cotter pin
r
can be installed.
LIGHTS
DAYTIME RUNNING LIGHT REPLACEMENT
To remove the headlight, do the following:
1. Disconnect the headlight to harness connection
q
.
2. Remove the three fasteners
w
retaining the headlight.
3. Remove the headlight from the inside of the front bumper.
94
MAINTENANCE
