BODY/STEERING/SUSPENSION
5.14
REAR DRIVE AXLE AND SWINGARM (ALL MODELS)
Vehicle Frame
Swing Arm
Rear Gearcase
Assembly
Wheel
Bearing
Axle
Skid Plate
Swing Arm Pivot Bolt
U--Bolt Nut & Washer
Axle Tube
60 ft. lbs.
(81 Nm)
Axle Tube
Retaining
Ring
150 ft. lbs.
(203 Nm)
Pivot Bushing
Swing Arm Bushing
Jam Nut
W asher
Grease Fitting
U--Bolt
Screw & Washer
40 ft. lbs.
(54 Nm)
Apply Loctitet 271
271 271
271
150 ft. lbs.
(203 Nm)
Screw & Washer
60 ft. lbs.
(81 Nm)
Wheel
Bearing
Bolt Lock
Bracket
30 ft.lbs.
(40 Nm)
Rubber Pad
60 ft. lbs.
(81 Nm)
Bolt & Washer
