BODY/STEERING/SUSPENSION
5.10
STEERING ASSEMBLY EXPLODED VIEW
Boots
Steering Box
Cap
Steering Wheel
Bushing
Tie Rod
Lower Steering Shaft
Tie Rod
Rod End & Jam Nut
Bolt
End Bolt
Upper Steering Shaft
Wave
Washers
Nut
242
Apply Loctitet 242
242
Screw & Nut
242
242
Screw & Lock Washer
242
