FUEL SYSTEM/CARBURETION
4.3
FUEL TANK ASSEMBLY
A
B
G
H
C
D
E
F
I
A. Fuel Line Components
B. Fuel Cap/Gauge
C. Fuel Tank
D. Tank Support
E. Fuel Pump
F. Fuel Filter & Line
G. Tank Secure Strap
H. Tank Venting
I. Tank Foil
Fuel Tank
Fuel Valve
Engine
Filter
Fuel Pump
Carburetor
Fuel Tank V ent
Carburetor V ent
Fitting Screens
L
L Located Above Oil Tank
FUEL FLOW DIAGRAM
