ELECTRICAL
10.21
STARTER SYSTEM TEST FLOW CHART,CON’T
Reconnect the solenoid. Connect the tester black
lead to the battery positive and the red lead to the
solenoid end and actuate the starter. Reading
should be less than
.1 V D.C.
Clean the battery-to-solenoid cable ends or
replace the cable.
Connect the black tester lead to solenoid end of
battery-to-solenoid cable. Connect red tester lead
to solenoid end of solenoid-to-starter cable.
Reading should be less than .1 V D.C.
Replace the starter solenoid.
Connect the black tester lead to the solenoid end of
the solenoid-to-starter cable. Connect the red tester
lead to the starter end of the same cable. The read-
ing should be less than .1 V D.C.
Clean the solenoid-to-starter cable ends or
replace the cable.
No
Yes
No
Yes
If all of these indicate a good condition, yet the starter still fails to turn, the
starter must be removed for static testing and inspection.
No
Yes
Voltage Drop Testing
See Page 10.16 for instructions.
Continued from previous page
Test B (from previous page)
