110
SPECIFICATIONS
RANGER 4X4 700 EFI
Maximum Weight Capacity 1500 lbs. (681 kg) (includes weight of operator,
passenger, cargo, accessories)
Dry Weight 1237 lbs. (561 kg)
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 3.25 qts. (3 l)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load 1000 lbs. (454 kg)
Overall Length 114 in. (289.6 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 76 in. (193 cm)
Cargo Box (L x W x H) 58 x 42 x 10 in. (147 x 106.7 x 25.4 cm)
Ground Clearance 12 in. (30.5 cm)
Min. Turning Radius 158 in. (401 cm)
Engine 4 valve 4 stroke twin cylinder with counter
balance
Displacement 683 cc
Bore x Stroke 80 x 68
Alternator Output 500 W @ 3000 RPM
Compression Ratio 9.40:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System ECU
Spark Plug / Gap RC7YC /.035 in. (0.9 mm)
Front Suspension Dual A-arm w/9.6 in. (24.4 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
