102
SPECIFICATIONS
RANGER TM
Gross Vehicle Weight 2400 lbs. (1089 kg)
Fuel Capacity 8.5 gal . (32.2 l)
Towing Capacity 1000 lbs. (454 kg)
Max. Cargo Box Load 750 lbs. (340 kg)
Overall Length 113 in. (282 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 51 in. (129.5 cm)
Wheelbase 76 in. (193 cm)
Ground Clearance 7.2 in. (183 mm )
Dry Weight 1050 lbs. (476 kg)
CargoBox(LxWxH) 58x42x10in.
(147 x 106.7 x 25.4 cm)
Min. Turning Radius 132 in. (335.3 cm)
Engine Oil Capacity 1.64 qts. (1.55 l)
Coolant Capacity NA
Engine 2 valve 4 stroke twin cylinder
Displacement 653 cc
Bore x Stroke 2-80 x 65
Pilot Jet 50
Main Jet 140
Needle Jet NA
Jet Needle NA
Air Screw 2.0
Alternator Output 360 W
Compression Ratio 8.3
Starting System Electric
Carburetor 27 mm Nikki
Ignition System Magneto
Ignition Timing 26_ @ 3600 rpm
Spark Plug BPR4EY
