106
SPECIFICATIONS
RANGER 4X4
Gross Vehicle Weight 2700 lbs. (1226 kg)
Fuel Capacity 8.5 gal . (32.2 l)
Towing Capacity 1500 lbs. (681 kg)
Max. Cargo Box Load 1000 lbs. (454 kg)
Overall Length 113 in. (282 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 75 in. (190.5 cm)
Wheelbase 76 in. (193 cm)
Ground Clearance 11.5 in. (29.2 cm)
Dry Weight 1185 lbs. (537 kg)
Cargo Box
(LxWxH)
58x42x10in.
(147 x 106.7 x 25.4 cm)
Min. Turning Radius 132 in. (335.3 cm)
Engine Oil Capacity 2qts.(2.1l)
Coolant Capacity 2.25 qts. (2.4 l)
Engine 4 valve 4 stroke single cylinder
with counter balance
Displacement 499 cc
Bore x Stroke 92x75
Pilot Jet 42.5
Main Jet 135
Needle Jet P-6 (829)
Jet Needle 4MB32-3
Air Screw 21/2
Alternator Output 250 W
Compression Ratio 10.2:1
Starting System Electric
Carburetor 34 mm CV Mikuni
Ignition System CDI
Ignition Timing 30_ @ 5000 rpm
Spark Plug NGK BKR5E
