SPECIFICATIONS
RANGER XP 1000 / 1000 ZUG
Maximum Weight
Capacity (includes
weight of operator,
passenger, cargo,
accessories)
738 kg (1627 lbs.)
Dry Weight 714 kg (1574 lbs.)
Test GVW - Rollover
Protection System
(ROPS)
1542 kg (3400 lbs.) per OSHA 29 CFR 1928.53
Fuel Capacity 43.9 l (11.6 gal)
Engine Oil Capacity 2.4 l (2.5 qts)
Coolant Capacity 4.75 l (5 qts.)
Overall Length 305 cm (120 in.)
Overall Width
159 cm (62.5 in.)
Overall Height 195 cm (77 in.)
Wheelbase
206 cm (81 in)
Cargo Box Dimensions
(Inside)
93 x 137 x 29 cm (36.5 x 54 x 11.5 in.)
Ground Clearance
33 cm ( 13 in)
Min. Turning Radius 401 cm (158 in.)
Towing Capacity 1136 kg (2500 lbs.)
Hitch Tongue Capacity 68 kg (150 lbs.)
Max. Cargo Box Load 454 kg (1000 lbs.)
Engine 4-Stroke DOHC Twin Cylinder
Displacement
999 cc
Bore x Stroke (mm)
93 mm x 64.4 mm
Alternator Output 660 W @ 3000 RPM
129
SPECIFICATIONS
