AIR FILTER
Inspect the air filter at the intervals outlined in the Maintenance Schedule, see
page 87. In extremely dusty conditions, air filter replacement will be required
more often. Access the air box near the right rear wheel.
1. Disengage the two cover latches
q
.
2. Unlatch the cover and carefully remove it from the air box.
3. Remove the filter
w
.
4. Inspect the air box for oil or water deposits. Wipe away any deposits with a
clean shop towel.
NOTICE
If the filter has been soaked with fuel or oil it must be replaced.
5. Inspect the air filter and replace if necessary.
NOTICE
DO NOT attempt to clean the air filter with compressed air .
6. Place the air filter into the air box and reinstall the air box cover.
NOTICE
Make sure the tabs are properly positioned into the hinge. Ensure the O-ring is
installed inside the lid properly.
7. Engage the cover latches.
104
MAINTENANCE
