OIL CHANGE
1. Position the vehicle on a level
surface. Set the parking brake.
2. Clean the area around the drain plug
q
.
3. Start the engine. Allow it to idle for
30 seconds.
4. Stop the engine.
WARNING
Hot oil can cause burns to skin. Do not allow hot oil to contact skin.
5. Place a drain pan under the engine crankcase.
6.
Remove the drain plug and pre-filter screen
w
. Allow the oil to drain
completely.
7. Wash the oil pre-filter screen with solvent to remove debris. Allow the screen
to air dry.
8. The external oil filter and oil cooler
e
are mounted to the chassis under the
engine. The oil filter is accessible on the right side of the vehicle. The spin-on
oil filter should be replaced when oil is changed. With the oil drained from the
crankcase, unscrew the oil filter and replace with a new one. Ensure that the
oil filter gasket is properly seated, lubricated with oil and in good condition.
Do not over tighten the oil filter.
TORQUE
External Oil Filter:
Turn by hand until filter O-ring contacts sealing surface, then turn an
additional 3/4 turn.
8. Reassemble the pre-filter screen
and spring to the pre-filter plug.
9. Reinstall the drain plug and tighten
to specification.
94
MAINTENANCE
