134
SPECIFICATIONS
RZR 4
Gross Vehicle Weight Rating 2206 lbs. (1000 kg)
Dry Weight 1255 lbs. (569 kg) (RZR 4)
1271 lbs. (576.5 kg) (RZR 4 EPS)
Test GVW - Rollover Protection
System (ROPS)
2250 lbs. (1021 kg) per OSHA 29 CFR 1928.53
Rear Cargo Box Capacity 300 lbs. (136 kg)
Maximum Weight Capacity
(Payload)
900 lbs. (408.2 kg) (riders/cargo/accessories/
trailer tongue weight)
Receiver Hitch Tongue Capacity 150 lbs. (68 kg)
Receiver Hitch Towing Capacity 1500 lbs. (680 kg
Fuel Capacity 7 gal. (26.5 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 5.5 qts. (5.2 l)
Rear Gearcase Oil Capacity 26 oz. (769 ml)
Demand Drive Fluid Capacity 6.75 oz. (200 ml)
Transmission Oil Capacity 24 oz. (710 ml)
Transfer Case Oil Capacity 14 oz. (414 ml)
Overall Length/Width/Height 130/60.5/75 in. (330/154/190.5 cm)
Wheelbase 103 in. (262 cm)
Ground Clearance 12 in. (30.5 cm)
Engine 4 valve 4 stroke twin cylinder with
counterbalance
Displacement 760 cc
Bore x Stroke 80mm x 76mm
Alternator Output 500 W @ 3000 RPM
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System ECU
Spark Plug / Gap RC7YC /.035 in. (0.9 mm)
Front Suspension Independent double a-arm with 12 in. (30.5 cm)
of travel
Rear Suspension Independent double a-arm with 12 in. (30.5 cm)
of travel
