9
9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
9.67
37. Check shock for any leaks.
NOTICE
If leakage from a remote shock reservoir hose fitting is
evident, check for a loose fitting and seal threads with
Three Bond 1215 (PN 2871557)
38. Reinstall the compression spring and the spring
retainer.
39. Thread the spring preload adjuster down against the
spring and set the preload to the specified
measurement (see Chapter 2 – Spring Adjustment).
40. Set the compression adjuster knob to the
recommended setting or the original setting upon
removal (see Chapter 2 – Shock Compression
Adjustment).
41. Remove the shock from the vise.
42. Reinstall spherical bearing O-rings and polyurethane
bushings.
NOTICE
After installation, be sure to RIDE SLOWLY initially to
ensure the shock and the vehicle’s suspension is
performing correctly.
STEERING / SUSPENSION
