SEAT ASSEMBLY REAR
q
Seat Frame
u
Plate Seat Latch
w
Screw 4 ft-lb (5 Nm)
i
Screw 4 ft-lb (5 Nm)
e
Seat Base Assembly
o
Bolt
r
Seat Latch Lever
a
Seat Bottom
t
Spring Seat Latch
s
Seat Back
y
Plate Seat Latch
