WALKER EVANS RACING® SHOCKS
q
Front Shock Preload Measurement
w
Rear Shock Preload Measurement
FACTORY DEFAULT PRELOAD SETTINGS
FACTORY DEFAULT PRELOAD SETTINGS
RZR XP
WALKER
Front
2.38 inches (60 mm)
Rear
6.00 inches (152 mm)
RZR XP 4
WALKER
Front
1.25 inches (32 mm)
Rear
5.25 inches (133 mm)
Follow these guidelines if you make adjustments to this suspension.
• Always return the suspension to the factory setting after the load is removed
from the vehicle. The increased suspension height will negatively impact
vehicle stability when operating without a load.
• Always apply the same adjustment setting to all four wheels.
Do not increase the spring preload by more than one inch (25.4 mm) over the
factory setting.
143
MAINTENANCE
