TIRE PRESSURE/LOAD WARNING (X2)
WARNING
Improper tire pressure or overloading can cause loss of control. Loss of control
can result in severe injury or death.
• Cold tire pressure:
Front: 7.0 psi (48.3 kPa)
Rear: 7.0 psi (48.3 kPa)
• Maximum weight capacity: 705 lbs. (320 kg)
• NEVER exceed 50 MPH (80 km/h) when rear cargo loads are above 75 lbs.
(34 kg) and/or front cargo loads are above 37 lbs. (17 kg).
• NEVER exceed 50 MPH (80 km/h) while carrying a passenger.
• NEVER exceed 10 MPH (16 km/h) when rear cargo loads are above 200 lbs.
(91 kg) and/or front cargo loads are 90 lbs. (41 kg).
• Lug nut torque values:
Steel rims 27 ft-lbs. (37 Nm)
Aluminum rims 30 ft-lbs. (41 Nm) + 1/4 Turn
CLUTCH COVER WARNING
WARNING
• Moving parts hazard under belt-clutch guard. To prevent serious injury, do not
operate vehicle with guard removed.
• Do not modify engine or clutch. Doing so can cause part failure, possible
imbalance, and excessive engine RPM, which can result in serious injury or
death.
HITCH CAPACITY LABEL (570/570 EPS/2X4/UTILITY
EDITION)
TRAILER MAX WEIGHT: 1225 LBS. (557 KG) ON LEVEL GROUND
HITCH MAX. VERTICAL WEIGHT: 120 LBS. (55 KG)
HITCH CAPACITY LABEL (570 SP)
TRAILER MAX WEIGHT:
1500 LBS. (682 KG) ON LEVEL GROUND)
850 LBS. (386 KG) UP TO 15° GRADE
HITCH MAX. VERTICAL WEIGHT: 150 LBS. (68 KG)
25
SAFETY
