ADC AWD MODE (IF EQUIPPED)
Move the momentary switch to the right, past the AWD setting, to engage ADC
AWD (if equipped). When the switch is on ADC AWD, the ADC system allows
engine braking to all four wheels when the vehicle descends a hill or incline.
Always move the AWD switch to ADC AWD before ascending or descending a
hill.
2X4 MODE
Move the momentary switch to the far left to operate in two-wheel drive (2X4).
AWD will disengage when engine speed slows to below 3100 RPM. The gauge
will display “2X4.”
ACTIVE DESCENT CONTROL (ADC) SYSTEM
The ADC system (if equipped) allows engine braking to all four wheels when the
vehicle descends a hill or incline. Always move the 4X4 switch to ADC 4X4
before ascending or descending a hill.
ENGAGING ACTIVE DESCENT CONTROL
The ADC system will automatically engage when all four of the following
conditions occur:
• The 4X4 switch must be in the ADC 4X4 position
• Vehicle speed must be 15 MPH (25 km/h) or less
• The throttle must be closed (throttle lever released)
• The transmission must be in gear (high, low or reverse)
DISENGAGING ACTIVE DESCENT CONTROL
The ADC system will automatically disengage if at least one of the following
conditions occur:
• The 4X4 switch is moved out of the ADC 4X4 position
• Vehicle speed exceeds 15 MPH (25 km/h)
• The throttle is open (throttle is applied)
• The transmission is shifted to neutral or park
• X2 Model: The vehicle is on flat ground, or not actively descending a hill
41
FEATURES AND CONTROLS
