56
CONTROLS AND FEATURES
Features
Instrument Cluster
Your Sportsman 700 is equipped with an instrument cluster which
senses vehicle speed from the right hand front wheel. The instrument
cluster measures distance in miles as well as hours of operation. It also
includes a reverse speed limiter function that limits the ATV’s speed at
approximately 7 to 9 mph. Refer to page 44 for additional information.
1 Rider Information Center
2 Speedometer needle - in addition to depicting vehicle speed, this
needle will flash indicating a fault condition.
3 Speedometer
2
3
1
CAUTION
Do not wash the instrument cluster with a high pressure washer.
Water under high pressure may enter the instrument cluster and
cause damage to the electronic components. Wash the unit by
hand or with a garden hose using mild soap. Do not use alcohol to
clean the instrument cluster. Do not allow gasoline to remain on
the instrument cluster.
