Polaris Trail Boss 330 User Manual

109
SPECIFICATIONS
Jetting Chart
Clutching Chart
TRAIL BOSS 330
Driving System Type Automatic PVT (POLARIS Variable Transmis-
sion)
Shift Type Side Lever (F/N/R)
Gear Reduction, Reverse 3.05:1
Gear Reduction, Forward 2.68:1
Drive Ratio, Final 3.64:1
Drive Chain 520 O-Ring
Tires/Pressure, Front 23 x 8-12 (5 psi/34.5 kPa)
Tires/Pressure, Rear 22 x 11-10 (5 psi/34.5 kPa)
Front Suspension MacPherson strut with 8.2" (21 cm) travel
Rear Suspension Progressive rate with 10.5" (26.7 cm) travel
Shock Adjustment CAM
Brakes, Front and Rear Single-Control Hydraulic Disc
Brake, Auxiliary Foot-Activated Hydraulic Disc, Rear Wheel
Brake, Parking Hydraulic lock, all wheel
Headlight 2 Dual Beam 30w/30w
Taillights 12V 5W
Brake Light 12V 26.9W
Battery 12V 14AH
Indicators High Temp/Neutral/Reverse
ALTITUDE
Meters (Feet)
AMBIENT TEMPERATURE
Below 40° F
(Below 5° C)
40° F and above
(5° C and above)
0-1800 (0-6000) 127.5 122.5
1800-3700 (6000-12000) 120 115
Altitude
Meters (Feet)
Shift
Weight
Drive Clutch
Spring
Driven Clutch
Spring
Helix/Spring/
Setting
0-1800
(0-6000)
10RHF
5632282
Blue/Gray
7042202
Black
7041782
40°
5131446
2+2
1800-3700
(6000-12000)
20-40
5631356
Blue/Gray
7042202
Black
7041782
40°
5131446
2+2
