82
MAINTENANCE
Lights
Indicator Lamp Replacement
1. Remove the instrument panel or front cover, if necessary, to access
the back of the indicator panel.
2. Using a small, straight-blade screwdriver, turn the base of the bulb
1/4 turn counterclockwise.
3. Using a needle-nose pliers or similar tool, pull the lamp out of the
indicator panel housing.
4. Insert the new bulb and seat it by turning it 1/4 turn clockwise.
5. Reinstall the instrument panel or front cover.
Taillight/Brakelight Lamp Replacement
1. From the rear of the brake-
light, remove the two
screws holding the lens
cover in place. Remove the
lens cover.
2. Remove the lamp and
replace it with a new lamp.
3. Test the light for proper
operation.
4. Reinstall the lens cover.
Screw
Lamp
Cover
To Next Page
