85
MAINTENANCE
Lights
NOTICE: Avoid touching a halogen bulb with bare fingers. Oil from skin leaves a
residue, causing a hot spot that will shorten the life of the lamp. If fin-
gers do touch the bulb, clean it with an alcohol-moistened towel.
Removing Halogen Bulbs
1. Pinch the ends of the spring (1)
together and lift until it releases
from the spring retainer.
2. Lift spring carefully around
wire harness (2) and flip to out-
side of housing.
3. With the wire harness attached
to the bulb (3), withdraw bulb
from housing.
4. Grasp bulb by metal base and
carefully separate bulb from
harness.
Installing Halogen Bulbs
1. Hold bulb by metal base and install into wire harness.
2. Insert bulb into housing.
3. Carefully flip spring back into housing placing it around wire har-
ness.
4. Squeeze spring together until it is over the spring retainer and
release.
5. Verify headlight aim.
