68
MAINTENANCE
Lubrication
Jackshaft Bearing
The jackshaft bearing on your model may be equipped with a grease fit-
ting, but this component is greased for life at the factory. Additional
lubrication is not required.
Driveshaft Bearing
Inject grease into the fitting on the
speedometer drive adaptor until
grease purges from inside or outside
the bearing seal (approximately two
pumps).
Throttle Cable
Lubricate the throttle cable lightly
with grease or oil. With the engine
off, turn the handlebars to the left
and lubricate liberally as shown.
Choke and Cable
Lubricate the choke slide and cables
lightly with oil or grease. Before
turning the engine off, operate the
choke intermittently to draw mois-
ture out of the choke plunger area
and reduce the possibility of the
choke becoming frozen.
Coupler Greasing
(WideTrak)
Grease the couplers on the drive-
shaft and jackshaft.
