- 9 -
System Connections
! Do not connect the power cord until all other connections have been made.
! Ensure that you observe the color cord when connecting audio and video cables.
Connecting to External AV Signal Source
Use the audio and video cable to connect the AV input jacks on the rear panel of the unit to the
external AV signal source.
After connection, turn on the power of the unit and the external AV signal source and then press the
INPUT button to shift to Composite mode.
