ID-E339-001GB 5
1.3.4 Fuse replacement
In the event of fuse replacement, an equivalent fuse replacement should be used: of the appropriate
type and nominal value. The appropriate types and nominal values are contained in table 2.3.
1.4 DEFINITIONS
Conventional detection line
A two-core line with non-addressable detectors installed in, terminated with an end-of-line resistor.
Fire warning device
An element installed in detection lines triggering a fire alarm, e.g. a fire detector, manual call point.
Line number
A consecutive number from the 1 ÷ 6 range, which is assigned to the control panel outputs where
detection lines are connected to.
Zone
A separated part of a supervised facility that specific warning devices forming one detection line are
allocated to.
Standard configuration
A set of data saved in the control panel memory defining default parameters set by the
manufacturer, such as delay times, disablements, alarm variants, etc.
Quiescent (supervision) mode
An operation mode, in which the control panel is power supplied from an electric energy source that
meets the settled requirements, during which no other operation mode is indicated.
Alarm (fire) mode
An operation mode the control panel triggers after receipt and verification of a fire occurrence signal
from fire warning devices.
Disablement mode
An operation mode, in which it is deliberately blocked the control panel ability to receive signals from
any fire warning devices and to evoke alarms, or the control panel output and/or transmission path
to any fire detection and alarm system component that is a part of alarm circuit.
Testing mode
An operation mode in which the control panel indicates functioning checking.
Fault mode
An operation mode in which the control panel indicates a fault of anything in alarm installation or its
own circuits.
2 DEVICE COMPLETENESS
Table 2.1 lists the set of items which compose the IGNIS 2040 control panel furnishings.
Table 2.2 specifies auxiliary equipment that can be installed in the IGNIS 2040 control panels. This
equipment should be ordered separately.
Table 2.3 contains a list of the fuses used in the control panel.
Table 2.1
Item
Description
Quantity
1
2
3
4
5
IGNIS 2040 fire detection and alarm control panel
Operation and Maintenance Documentation (OMD)
Servicing manual
Warranty certificate
Control panel unit package
1
1
1
1
1
