3) Mount the damper controller on the top of the motorised
damper, or installed elsewhere close to the motorised damper.
Plug the bridge cable into the damper port on the damper
controller and the motor.
Warning - Do not plug the damper controller into any
other motorised damper except a Polyaire authorised one.
4) Apply the power to the transformer by plugging in the
transformer into the 240VAC power outlet.
5) Plug the 24VAC power supply into the socket on the last
damper controller at the end of the control bus. The LED light
on the damper controller should be on. Otherwise, check the
power supply and the connection.
Page 6
