Polygroup CP2000-S - 6-PORT VALVE SETUP

20
6-PORT VALVE SETUP
2. Fit the Gasket in place.
1. Using the Wrench, twist counterclockwise to loosen and remove the Locking Ring.
3. Insert the Top Cover O-Ring into the groove of the Valve Housing.
Valve Gasket
Top Cover O-Ring
Valve Housing
