POLYPRINT SA – TEXJET OPERATION MANUAL V6.4 EN
- 35 -
Place the Polo plate over the 2 long interface brackets and screw the 4
countersunk hex screws.
Universal plate
The Polo plate includes the following items.
1 Universal plate
4 countersunk hex 2,5mm screws
2,5mm Alen metric wrench tool
