19
11.1. Foil guard
A foil guard is positioned in one corner, it consists of a bar sensoring the wrapped foil, if only
1 layer of foil is used. If the foil tears the bar will fall down and activatesa switch that stops
the machine. Pushing Start or Foil will restart the machine, till the foil guard has contact with
the foil again.
12. Bottom foil bracket
The bottom foil bracket consists of some boxes placed on the chassis frame for two rolls of
bottom foil. The foil is fed through the foil tube and the bales are positioned on it.
