3.
4.
Hold the wiper blade assembly with one hand and
pull
the
element gently with the other hand.
(Replacement blade elements have
three
plastic caps
which retain two metal flexor strips.
Do
not remove
these caps before the element
is
installed.)
At
the
heel end of the blade assembly, notched end
of blade element last, slide the blade element into the
blade claw sets.
The
plastic retainer caps will be
forced off as the element is fully inserted. Make sure
that all the claw sets
are
properly engaged in
the
slots of the blade element.
Install
wiper
blade
assembly
on
wiper
arm.
For information on windshield wiper blade replacement
type
and
length,
see
“Capacities
and
Specifications” in
the
Index.
Headlamp
Aiming
Your vehicle
has
the headlamp system. These headlamps
have horizontal and vertical aim indicators. The
aim
has been pre-set at the factory and should need
no
further
adjustment.
If
your
vehicle
is damaged in
an
accident and
the
headlamp
aim
seems to be affected, see your Pontiac
dealer. Headlmps on damaged vehicles may require
recalibration of
the
horizontal
aim
by
your
Pontiac dealer.
To
check the aim, the vehicle should be properly
prepared
as
follows:
a
The vehicle must have a11 four tires
on
a!
perfectly
level surface.
The vehicle should not have any snow,
ice
or mud
There should not be any ‘cargo or loading
of
the
attached tu
it.
vehicle, except it should have a full tank of gas and
one person or
160
lbs.
(75
kg)
on the driver’s seat.
e
Tires
should be properly inflated.
The
horizontal indicator should
read
“0.”
NOTICE:
To
make
sure
your headlamps are aimed
properly, read
all
the
instructions before
beginning.
Failure
to
follow
th’ese
instructions
could
cause damage to headlamp parts.
State inspection
stations
will
allow a vertical reading of
plus
0.76
degrees
or
minus
0.76
degrees fr0m the center
of
the bubble.
6-48
