362 Minor Repairs
Fuse assignment – fuse box in Cayenne engine compartment
Note
f Use the plastic grippers from the fuse boxes in the dashboard to replace the fuses.
No. Designation Rating in A
1 Fan 60
2Fan 30
3 not used
4 not used
5 not used
6 not used
7 Ignition coils 15
8 Ignition coils 15
9 Engine control unit, high-pressure fuel injectors, throttle adjusting unit 20
10 Water run-on pump, tank leakage detection, carbon canister shut-off valve, fan, pressure sensor for air conditioner 10
11 Air-conditioning compressor, service interval sensor, crankcase vent 10
12 Camshaft adjustment, tank vent, quantity control valve 15
13 Fuel pump, right 15
14 Fuel pump, left 15
15 Engine control unit, main relay 10
16 not used
17 Oxygen sensors ahead of catalytic converter 15
18 Oxygen sensors behind catalytic converter 7,5
