Minor Repairs 363
Fuse assignment – fuse box in Cayenne S engine compartment
Note
Use the plastic grippers from the fuse boxes in the dashboard to replace the fuses.
No. Designation Rating in A
1 Fan 60
2Fan 30
3 not used
4 not used
5 not used
6 not used
7 Ignition coils 15
8 Tank vent, air-conditioning compressor, intake pipe switchover, crankcase vent 15
9 Quantity control valve, camshaft adjuster, valve lift adjuster 15
10
Engine components: Cooling air output stages, carbon canister shut-off valve, pressure sensor for air conditioner,
tank leakage detection, exhaust flap control valve, Hall sensor, oil-level sensor
10
11 Engine control unit, high-pressure fuel injectors, throttle adjusting unit 20
12 not used
13 Fuel pump, right 15
14 Fuel pump, left 15
15 Engine control unit, main relay 10
16 not used
17 Oxygen sensors ahead of catalytic converter 15
18 Oxygen sensors behind catalytic converter 7,5
