PACCYC03A
CYCLONE 2200 PARTS
19
ITEM# PART # DESCRIPTION ITEM# PART # DESCRIPTION
1 BLOWER-02 BLOWER HOUSING - CYCLONE2000 16 MOTOR-016-01 CYCLONE2000 - 2SPD MOTOR
2 BLOWER-WHL-2CW CYCLONE2000 BLOWER WHEEL (PART 1) 17 PAC-PLB-14 INLET HOSE ADAPTER for CYCLONE2000
3 BLOWER-WHL-3CCW CYCLONE2000 BLOWER WHEEL (PART 2) 18 PAD6019/22 KUUL PAD SET FOR CYCLONE2200
4 BONNET-06 22.5” EXTRUDED BONNET-CYCLONE2000 19 POWERCORD-02F 10ft POWER CORD W / DOME STRAIN RELIEF
5 BOX-UL-02 1 & 2 SPD UL ELECTRICAL BOX 20 PUMP-BRACKET-6 PUMP MOUNT BRACKET-CYCLONE2000
6 CAPACITOR-04 RUN CAPACITOR FOR CYCLONE2000 21 PUMP-CYC-3 CYCLONE PUMP - OK400
7 CASTER-3-L 3” LOCKING CASTERS 22 S-002 #8 x 3/4” TEK SCREW
8 CASTER-3-NL 3” CASTERS 23 S-007 5/16 -18 x 3/4 TRUSS HEAD SCREW
9 CLAMP-01 1/2” WIRE SPRING CLAMP 24 S-011 #8 x 9/16” WASHER HEAD SCREW
10 CTRL-2SPD-01 2-SPEED SWITCH ASSEMBLY 25 SPRAY-CYC-02 SPRAY BAR FOR CYCLONE2000
11 CTRL-VLV-BRKT VALVE-01 MOUNTING BRACKETS 26 SPRAY-ACC-01 SPRAY BAR CLIP
12 DRAIN-PLUG-01 DRAIN PLUG 27 SWITCHPL-2SPD-T 2 SPEED SWITCH PLATE
13 FLAP-CYC-2 FLAP/SPLASHGAURD-CYCLONE2000 28 TOG-BOOT-01 RUBBER TOGGLE SWITCH BOOT (2)
14 FLOAT-CYC-03 FLOAT VALVE 29 VALVE-01 PUMP TO SPRAY BAR CONTROL VALVE
15 LOUVERS-CYC-11 LOUVER W/MESH - CYCLONE2000 30 TUBE-01 PUMP TO SPRAY BAR TUBING
