Setthecrossbar(12)atdesireddistancefrombladeand
tightenscrew.Forripping,thecrossbarshouldbedown
andagainstthestraightedgeoftheworkpieceasshown.
When circle cutting, adjust rip fence so that distance from
bladetoholeinfencearm(13)isatthedesiredradius
andtightenscrew.Placesawsothatholeinfence arm is
overcenterofcircletobecut(drillholeforbladeorcut
inwardfromedgeofmaterialtogetbladeintoposition).
When saw is properly positioned, drive a small nail
through hole in fence arm. Using rip fence as a pivot
arm,begincuttingcircle.Forcirclecutting,thecrossbar
should be up, as shown in figure H.
POCKET CUTTING (FIGURE I)
Apocketcutisaneasymethodofmakinganinsidecut.
The saw can be inserted directly into a panel or board
withoutfirstdrillingaleadorpilothole.Inpocketcutting,
measurethesurfacetobecutandmarkclearlywitha
pencil.Nexttipthesawforwarduntilthefrontendofthe
shoesitsfirmlyontheworksurfaceandthebladeclears
theworkthroughitsfullstroke.Switchthetoolonand
allowittoattainmaximumspeed.Gripthesawfirmlyand
lowerthebackedgeoftoolslowlyuntilthebladereaches
itscompletedepth.Holdtheshoeflatagainstthewood
andbegincutting.Donotremovebladefromcutwhileitis
still moving. Blade must come to a complete stop.
MAINTENANCE
Useonlymildsoapanddampclothtocleanthetool.Never
letanyliquidgetinsidethetool;neverimmerseanypartof
thetoolintoaliquid.
REPLACEMENT PARTS
Useonlyidenticalreplacementparts.Forapartslistortoorderparts,visitourservicewebsite
atwww.portercable.com.YoucanalsoorderpartsfromyournearestPORTER-CABLEFactory
ServiceCenterorPORTER-CABLEAuthorizedWarrantyServiceCenter.Or,youcancallour
CustomerCareCenterat(888)848-5175.
SERVICE AND REPAIRS
Allqualitytoolswilleventuallyrequireservicingand/orreplacementofparts.For
informationaboutPORTER-CABLE,itsfactoryservicecentersorauthorizedwarranty
servicecenters,visitourwebsiteatwww.portercable.comorcallourCustomerCare
Centerat(888)848-5175.Allrepairsmadebyourservicecentersarefullyguaranteed
againstdefectivematerialandworkmanship.Wecannotguaranteerepairsmadeor
attempted by others.
YoucanalsowritetousforinformationatPORTER-CABLE,4825Highway45North,
Jackson,Tennessee38305,(888)848-5175-Attention:ProductService.Besureto
includealloftheinformationshownonthenameplateofyourtool(modelnumber,type,
serialnumber,etc.).
ACCESSORIES
WARNING: Sinceaccessories,otherthanthoseofferedbyPORTER-CABLE,
have not been tested with this product, use of such accessories with this tool could be
hazardous.Toreducetheriskofinjury,onlyPORTER-CABLErecommended
accessories should be used with this product.
AcompletelineofaccessoriesisavailablefromyourPORTER-CABLEFactoryService
CenteroraPORTER-CABLEAuthorizedWarrantyServiceCenter.Pleasevisitour
WebSitewww.portercable.comforacatalogorforthenameofyournearestsupplier.
