Porter-Cable PCXB515BG - Table of Contents; Product Specifications

2
2016/09
TABLE OF CONTENTS
SECTION PAGE
PRODUCT SPECIFICATIONS ................................................................................... 2
SAFETY GUIDELINES - DEFINITIONS ..................................................................... 3
POWER TOOL SAFETY ............................................................................................. 4
BENCH GRINDER SAFETY ....................................................................................... 6
ELECTRICAL REQUIREMENTS AND SAFETY ........................................................ 8
TOOLS NEEDED FOR ASSEMBLY ........................................................................... 10
CARTON CONTENTS ................................................................................................ 10
KNOW YOUR BENCH GRINDER .............................................................................. 12
ASSEMBLY AND ADJUSTMENTS ............................................................................. 13
OPERATION ............................................................................................................... 16
MAINTENANCE .......................................................................................................... 18
ACCESSORIES AND ATTACHMENTS ...................................................................... 18
TROUBLESHOOTING GUIDE ................................................................................... 19
PARTS LIST................................................................................................................. 20
WARRANTY................................................................................................................. 24
PRODUCT SPECIFICATIONS
To avoid electrical hazards, re hazards or damage to the tool, use proper circuit
protection. Use a separate electrical circuit for your tools. The grinder is wired at the
factory for 110-120 Volt operation. It must be connected to a 120 V, 2.1 AMP branch circuit
and use a 2.1 AMP time delay fuse or circuit breaker. To avoid shock or re, replace
power cord immediately if it is worn, cut or damaged in any way.
Printed in China
WARNING
!
MOTOR WHEEL
Power Source .…. 120 V AC, 60 Hz, 2.1 A Diameter ......................... 6 in. (150 mm)
Speed (No load) .. 3450 RPM Face ................................ 3/4 in. (20 mm)
Type .................... Induction Hole …......…................... 1/2 in. (12.7 mm)
Shaft Diameter .... 1/2 in. (12.7 mm) WORK LIGHT
LED
