9
This tool is for indoor use only. Do not expose
to rain or use in damp locations.
This tool is intended for use on a circuit that
has a receptacle like the one illustrated in
Fig. 1. Fig. 1 shows a three-pronged electrical
plug and receptacle that has a grounding
conductor. If a properly grounded receptacle
is not available, an adapter (Fig. 2) can be
used to temporarily connect this plug to
a two-contact grounded receptacle. The
adapter (Fig. 2) has a rigid lug extending from
it that MUST be connected to a permanent
earth ground, such as a properly grounded
receptacle box.
In all cases, make certain the receptacle is
properly grounded. If you are not sure, have a
qualied electrician check the receptacle.
WARNING
!
CAUTION
!
Fig. 1
Fig. 2
Three-Pronged Plug
Grounding Prong
Properly Grounded
Three-Pronged
Receptacle
Grounding Lug
Make sure this is
connected to a
known ground.
Two-Pronged
Receptacle
Adapter
GLOSSARY OF TERMS
WHEEL GUARD - Covers the grinding
wheels and protects against accidental
contact.
WHEEL COVER - Covers the grinding wheels
and provides access for routine maintenance.
MOTOR HOUSING - Contains the electrical
motor.
MOUNTING FEET - Helps to minimize
vibration of the grinder.
EYE SHIELD MOUNTS - Supports the eye
shields.
EYE SHIELDS - Protective Lexan
see-thru shields to prevent any loose debris
from contacting the operator. SPARK
ARRESTORS - Prevents hot sparks and
debris from contacting the operator.
TOOL REST ADJUSTABLE SUPPORTS - Let
the operator position the tool
rest closer to the wheel as the wheel
decreases in diameter due to wear. TOOL
RESTS - Used to support the workpiece that
is being ground Adjustable to provide angled
surfaces.
GRINDING WHEEL 60 GRIT - Used to
remove light material from workpiece.
GRINDING WHEEL 36 GRIT - Used to
remove heavy material from workpiece. ON /
OFF SWITCH - Used to turn "ON" and turn
"OFF" the grinder. MOUNTING PAD - Used to
secure the grinder to a workbench or suitabte
work surface.
GRINDING WHEEL IDENTIFICATION LABEL
- Provides information on wheel size, grit and
maximum rpm. FLANGES - Used to secure
the grinding wheels to the grinder and
distribute the load of the lock nuts.
LOCK NUT - Used to secure the grinding
wheels to the grinder.
