Porter-Cable PCXB620DP - Drill Press Components and Terms; Know Your Drill Press Components

12
KNOW YOUR DRILL PRESS
Spindle pulley
Motor pulley
Front
Rear
Pulley cover
Belt tension
lock knob
Table crank
handle
Rack
Table bracket
Motor
Chuck key holder
Pulley cover
Mounting holes
Table
Chuck
Column
ON/OFF
switch with
safety key
Hex head
lock screws
ON/OFF LED
light switch
Depth scale
pointer
Quill return
coil / spring
Depth stop
nuts
LED light
Table lock
handle
Bevel lock
bolt
Base
Feed
handles
Rack ring
